Brief Introduction
In BenleyTechTM, a high-end TFT GF2 LCD display panel will be used for iPhone 6S Plus replacement screen production to win our returning aftermarket iPhone screen distributors. Combined with clients’ feedback, additional replacement component material quality control, and assembly technology improvement, our solution will save distributors’ time and money cost in the long run.
Compatibility
Perfect for screen repair & replacement for Apple iPhone 6S Plus models below.
- iPhone 6S Plus Space Gray – A1634, A1687, A1690, and A1699
Key Features
- Great Color Saturation & Brightness
- P3 Wide Gamut Display
- Enhanced Specular Reflector
- Cold Glue Pressed Frame
- OEM Quality Flexible FPC
- Front Camera Frame and Earpiece Mesh Pre-installed
Specification Datasheet*)
| Model Number | TFT-IP6SP-Black |
| Bezel Color | Black |
| Diagonal | 5.5” |
| Weight | 72.4 g with LCD Steel Shield |
| Resolution | 1920 x 1080, 401 ppi |
| Dimensions | 155.75 x 75.4 x 2.9 mm |
| Active Area | 120.960 x 68.240 mm |
| Brightness | Typ. 400 ± 50 cd/m2 |
| Contrast Ratio | Typ. 1300 : 1 |
| Color Temperature | 7000 ± 1500 K |
| Polarizing Test | Good Vision All Angles |
| Oleophobic Coating | Yes, and More Durable |
| 3D Touch | No |
| True Tone | No |
| Color Gamut | Typ. 85.6% |
| Operating Temperature | -20°C to 70°C |
| Storage Temperature | -30°C to 80°C |
* Please note that specific quality requirements are outlined in our production contract and confirmed specifications. This table does not replace or modify any terms or obligations outlined in said contract or specifications.
Screen Details
Below will show you our GF2 TFT LCD replacement screen details coming with the concept of improving both display performance and iPhone repairing convenience.
Flex Cable
High Quality Material Flex and Connectors
Oleophobic Coating
No Blurs, No Dust Left, Sensitive and Smooth Touch Response, High Color Resolution and Brightness, Wide Color Temperature, and Tempered H9 Glass.
Strong Middle Frame and Small Parts Preinstalled
Small parts like the sensor holder, earpiece anti-dust mesh, and camera holder are preinstalled.
All Benleytech replacement LCD frames are with cold glue technology, strong and durable, with no fading.
